name: home-lab
description: Control the home lab where you(personal assistant running inside OpenClaw) are running on
---

# Home Lab

Control home lab Linux machines via bash and SSH commands.

## Conduct of Code

Always provide a clear, high-level explanation of your action plan before executing the first step. Let the user understand and confirm the plan before proceeding.

Always request confirmation before executing any command that may change system state, such as rebooting the OS, modifying configuration files, or restarting services. Clearly explain what the command does and why it is necessary before asking for confirmation.

## Home Lab Environment

All Linux machines use the same username: `mark`. SSH login does not require a password.

### Linux Machines

- 192.168.1.58 : Raspberry Pi, always on
- 192.168.1.68 : Raspberry Pi, always on
- 192.168.1.108 : Raspberry Pi, always on
- 192.168.1.14 : X86_64 server

### Observability and Monitoring

A Prometheus instance runs on 192.168.1.74:9090. Metrics are collected by Node Exporter on each machine.

When users request metrics (temperature, CPU usage, memory usage, disk usage), first query Prometheus. Only execute remote SSH commands if the required metrics cannot be found in Prometheus.

If you are unfamiliar with the Prometheus API, load the `prometheus-api` Skill.

Note that Prometheus metrics may not always be real-time. If real-time data is required, execute a remote SSH command.

### Services running on the machines

#### 192.168.1.68
This machine acts as the main Internet gateway of the home lab.

Access this machine in read-only mode. Do not change anything without explicit confirmation.

##### Home Assistant
The home automation system. Access by http://192.168.1.68:8123

##### OpenClaw
An OpenClaw instance runs at http://127.0.0.1:18789. It may be you or may be another AI assistant.

#### 192.168.1.74

##### Prometheus

Base URL: `http://192.168.1.74:9090`

All machines are monitored via Node exporter, with metrics collected by this Prometheus server.

## Remote wake up

Wake up 192.168.1.14 using:
```bash
ssh mark@192.168.1.108 o
```

1
2
3
4

curl -s -X POST $HA_URL/api/webhook/ai-speak \
  -H "Content-Type: application/json" \
  -H "Authorization: Bearer $HA_TOKEN" \
  -d '{"msg": "需要播报的内容"}'

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49

---
name: homeassistant
description: Control Home Assistant - smart plugs, lights, scenes, automations.
homepage: https://www.home-assistant.io/
metadata: {"clawdis":{"emoji":"🏠","requires":{"bins":["curl"],"env":["HA_TOKEN"]},"primaryEnv":"HA_TOKEN"}}
---

# Home Assistant

Control smart home devices via Home Assistant API.

## Setup

Set environment variables:
- `HA_URL`: Your Home Assistant URL (e.g., `http://192.168.1.100:8123`)
- `HA_TOKEN`: Long-lived access token (create in HA → Profile → Long-Lived Access Tokens)

## Quick Commands

### Smart Speaker Integration 🔊
There is a smart speaker you can control. You can control it to speech any text to the user. You can use it to send notification to user at home.

```bash
curl -s -X POST $HA_URL/api/webhook/ai-speak -H "Content-Type: application/json" -H "Authorization: Bearer $HA_TOKEN" -d '{"msg": "The message you want to speech to user"}'
```

### List entities by domain
```bash
curl -s "$HA_URL/api/states" -H "Authorization: Bearer $HA_TOKEN" | \
  jq -r '.[] | select(.entity_id | startswith("switch.")) | .entity_id'
```

### Turn on/off
```bash
# Turn on
curl -s -X POST "$HA_URL/api/services/switch/turn_on" \
  -H "Authorization: Bearer $HA_TOKEN" \
  -H "Content-Type: application/json" \
  -d '{"entity_id": "switch.office_lamp"}'
```

### Control lights
```bash
# Turn on with brightness
curl -s -X POST "$HA_URL/api/services/light/turn_on" \
  -H "Authorization: Bearer $HA_TOKEN" \
  -H "Content-Type: application/json" \
  -d '{"entity_id": "light.living_room", "brightness_pct": 80}'
```
